serise of extruder

serise of extruder

  • Min.Order Quantity: 1 Set
  • Supply Ability: 1 Set per Month
  • Port: qingdao
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:2016-03-16
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Place of Origin:  jian
  • Brand Name:  Xin BEIFA
  • Model Number:  XBF60-I,XBF65-II,XBF70-II,XBF85-II,

serise of extruder

main features

XBF60-I Single extruder is consisting of feeding system,extruding system,cutting system,heating system,gearing system and controlling system.

Features

1.Consists of feeding system,extruding system and cutting system,adopts frequency speed-controlling with high automation and stable performation.

2.Automatic lubricating,cooling,to guarantee the extruder running safely.

3.According to different material,to choose the raletive single or double screw feeding system,the material should be uniformity and stable.

4.Screw is made by special technique,is able to bear grinding,steady and reliable.

5.According to different screw design rate to full different technology request.

Technical Paramet

Model Installed power Actual consumption  Main power  Output    Dimension     Products

XBF60-I  20KW         15.75KW         11.25KW  100kg/h  2.48*0.96*2.1m Frying or

without frying food

XBF65-II  35KW        28KW            22KW   120-150kg/h 2.5*1*1.8m   Frying or

without frying food

XBF70-II 65KW        40KW            30KW  150-200kg/h 3.5*1*1.8m   pet/

protein/snack food

XBF85-II  120KW       60KW          90KW      300-500KW 4*1.2*3m    pet/

protein/snack food

Double-screw Test Extruder

XBF32-II Double-screw testing inflating extruder is a new type of extruder adopts different kinds

of extrusion theory and features,fits for various techniques.When adjust the parameter in

practice,and appears with figure,choose different screws to fit different raw material extruding

demand,which settles the problem between teaching reseaching theory and practice .It supplies an

 economic experience measure for teaching and reseaching.

Main features

 1.Monopoly design,the first mini-type multifunction twin-screw                                                                                                                                 inflating machine in China

2.Widely used,according to different material and product character,use many screws/machina

barrels of different length combination,fit for various material experiments.

3.Special distributor case and bearing,to improve the eatruder performance.

4.Multipoint temperature control and pressure measure point.

5.Advanced touching screen,HMI and help system,display a lot of real time parameters and record

working status of each equipment and print the numbers out.

Technique parameter

Output          8-12kg/h

Feeding power    0.18kw

Driving power    4-7.5kw

Cutting power    0.25kw

Heating power    2.1-3.5kw

Oil pump power   0.12kw   Dimension       2-2.5*0.6*1.5m






  • Place of Origin:  jian
  • Brand Name:  Xin BEIFA
  • Model Number:  XBF60-I,XBF65-II,XBF70-II,XBF85-II,
